Adaptable to nearly any type of control system

  • 10 transistor controlled outputs 24V
  • 1 analogous output 0-5V or 0-10V, selected by jumper
  • selection up to 7 axis (through software adaption to 28)
  • free definition of axis names
  • 3 feeding speeds
  • rasterized handwheel with 100 ppr
  • encoder output RS422 or TTL
  • increments are shown on the display
  • LCD display for status informations
  • 16 channels available
  • working range up to 25m
  • running time of akkus up to 10h
  • processor driven charging station
  • vibration alarm when leaving working range
  • emergency stop, 2 circuits
  • 2 safety buttons (side)
  • safety category 3 in compliance with EN 954-1

Special solutions through software adaptions:
 i.e. machines with 6 axis and 4 axis groups (total of 24 axis)

New Accesspoint HBG 222-AP:

  • up to 16 transistor outputs
  • 2 safety circuits (optional: galvanic separation)
  • selection button instead of poti possible
    •
  • replacement for Mini BHG from Siemens

Downloads: Flyer HBG 220-RF, Connection diagram

Downloads: Connection diagram HBG 222-AP
